Features & Benefits
- Durable ceramic based inks fired during tempering;
- Suitable for internal cladding and spandrel applications;
- High opacity colour range.
Applications
Residential and commercial glazing.
Range
6mm Deep Black, Cool White, Anthracite Grey colours.
Design and Glazing Notes
For cladding, paint side of glass is fixed directly to the wall. We do not recommend ‘two way’ viewing or any sort of ‘backlighting’ due to possible pin holing or surface imperfections. IGU’s and tempered laminated glass applications are possible with paint surface to position #4.
How to Specify
- Select either 6mm Deep Black, Cool White, Anthracite Grey colours;
- Single or IGU and either Toughened, Toughened Heat Soaked, Heat Strengthened or Toughened or Heat Strengthened Laminated;
- All glass to be selected and installed in accordance but not exclusively to the following Australian Standards;
AS 1288 Glass in buildings – Selection and installation
AS 2208 Safety glazing materials in buildings
AS 4666 Insulating glass units
AS/NZS 4667 Quality requirements for cut-to-size and processed glass
AS 1170 Wind & Structural Design Actions
