Features & Benefits
- Available in white colour only;
- Durable ceramic based inks;
- Grade “A” toughened and tempered laminated safety glass and heat strengthened glass.
Applications
Residential and commercial glazing.
Size Limits*
Maximum Size – 5000mm x 2400mm
Minimum Size – 400mm x 400mm
Glass Thickness - 4mm-19mm
*subject to glass types, thickness and design specifications.
Design & Glazing Notes
How to Specify
- Select ImageTek™ S1 Extra Durable
- Select appropriate thickness and process;
- Toughened, Toughened Heat Soaked, Heat Strengthened or Toughened or Heat Strengthened laminated glass single and IGU.
- All glass to be selected and installed in accordance but not exclusively to the following Australian Standards;
AS 1288 Glass in buildings – Selection and installation
AS 2208 Safety glazing materials in buildings
AS 4666 Insulating glass units
AS/NZS 4667 Quality requirements for cut-to-size and processed glass
AS 1170 Wind & Structural Design Actions
